The NHK Osaka Broadcasting Station and Osaka Museum of History were built in the ruins of Namba Shrine located in the southwestern area of Osaka Castle. Fujitec supplied and installed 12 elevators in the 18-story broadcasting station and a total of 28 elevators and escalators in the 13-story museum. In the common atrium, a total of five elevators and escalators are in operation.
| Model | Use | Loading (kg) | Capacity (person) | Speed (m/min) | Stop number of floors (floor) |
unit |
|---|---|---|---|---|---|---|
| AC-GL | Passenger | 1600 | 24 | 180 | 3 | 3 |
| AC-GL | Passenger | 1600 | 24 | 180 | 8 | 1 |
| AC-GL | Passenger | 1450 | 22 | 240 | 13 | 2 |
| AC-GL | Passenger | 1300 | 20 | 150 | 14 | 2 |
| AC-GL | Passenger | 1150 | 17 | 240 | 12 | 3 |
| AC-GL | Passenger | 1150 | 17 | 240 | 5 | 1 |
| AC-GL | Service | 2050 | 28 | 210 | 21 | 1 |
| AC-GL | Service | 1150 | 17 | 210 | 21 | 1 |
| AC-GL | Service | 1150 | 17 | 150 | 20 | 1 |
| EXCELDYNE | Service | 4750 | 73 | 60 | 16 | 1 |
| EXCELDYNE | Service | 1900 | 29 | 45 | 5 | 1 |
| EXCELDYNE | Freight | 5000 | - | 45 | 4 | 1 |
| EXCELDYNE | Freight | 2300 | - | 45 | 8 | 1 |
| HYDRAULIC | Passenger | 750 | 11 | 60 | 3 | 1 |
| Model | Type | Step width (mm) | Floor height (mm) | Incline (degree) | unit |
|---|---|---|---|---|---|
| V | S | 1200 | 5600 | 30 | 2 |
| V | S | 1200 | 4190 | 30 | 2 |
| V | S | 1200 | 3710 | 30 | 2 |
| V | S | 1200 | 4050 | 30 | 9 |
| V | S | 1200 | 3375 | 30 | 6 |
| PLS | S | 1200 | 6075 | 30 | 2 |
| PLS | S | 1200 | 7425 | 30 | 2 |
