Located in southeast Osaka Bay, the Kansai International Airport is the first major 24-hour airport in Japan to operate on a man-made island. Fujitec installed a total of 35 elevators and 26 escalators in the airport buildings including this terminal, as well as the Airport Administrative Facility and Kansai Airport Station.
| Model | Use | Loading (kg) | Capacity (person) | Speed (m/min) | Stop number of floors (floor) |
unit |
|---|---|---|---|---|---|---|
| HYDRAULIC | Pssenger | 750 | 10 | 45 | 2 | 8 |
| AC-GD | Pssenger | 450 | 6 | 45 | 2 | 1 |
| AC-GD | Service | 1600 | 21 | 60 | 5 | 8 |
| AC-GD | Service | 1150 | 15 | 60 | 5 | 8 |
| AC-GD | Service | 1600 | 21 | 60 | 3 | 2 |
| HYDRAULIC | Service | 1600 | 21 | 45 | 2 | 2 |
| HYDRAULIC | Service | 1800 | 24 | 45 | 4 | 1 |
| HYDRAULIC | Service | 3000 | 40 | 30 | 2 | 1 |
| HYDRAULIC | Bed | 750 | 10 | 45 | 3 | 1 |
| HYDRAULIC | Bed | 750 | 10 | 45 | 2 | 1 |
| HYDRAULIC | Freight | 1250 | - | 45 | 2 | 2 |
| Model | Type | Step width (mm) | Floor height (mm) | Incline (degree) | unit |
|---|---|---|---|---|---|
| PLS | F | 1200 | 4640 | 30 | 10 |
| PLS | F | 1200 | 6960 | 30 | 8 |
| PLS | F | 1200 | 4250 | 30 | 2 |
| PLS | S | 1200 | 3480 | 30 | 6 |
