Otemachi Place

"Otemachi Place" consists of two office buildings that are among the largest in Otemachi, Tokyo's top business district.
Thirty-two Fujitec elevators and 31 Fujitec escalators were supplied to Otemachi Place. Three 14-meter high-rise escalators each were installed in the entrances of the West Tower and East Tower to assist businesspeople headed for the lobby floor.

  • Elevator
  • Escalator
  • Office
  • Japan
  • Observation
  • Lantern
  • Capacity:over 1150kg
  • Capacity:under 1150kg
  • Speed:over 150m/min
  • Step:600mm
  • Step:1000mm
  • Outdoor
  • Rise:over 8000mm
  • 2010s
Building name
Otemachi Place
Address
Otemachi, Tokyo
Client
WEST TOWER: NTT Urban Development Corporation / EAST TOWER: Urban Renaissance Agency
Design and supervision
WEST TOWER: NIHON SEKKEI, INC. / EAST TOWER: Obayashi Corporation
Construction
WEST TOWER: Takenaka Corporation / EAST TOWER: Obayashi Corporation
Completion
2018

Specifications

Elevator Total units 32
Model Use Loading (kg) Capacity (person) Speed (m/min) Stop number of
floors (floor)
unit
Order XIOR Passenger 1150 17 90 5 2
Order XIOR Passenger 1050 16 90 4 1
Order XIOR Passenger 1000 15 60 4 1
AC-GL Passenger 1800 27 150 9 13
AC-GL Passenger 1800 27 240 10 7
AC-GL Passenger 1800 27 240 9 6
AC-GL Servive 3000 39 180 35 1
AC-GL Servive 1600 24 180 35 1
Escalator Total units 31
Model Type Step width (mm) Floor height (mm) Incline (degree) unit
GS-NX S 1000 14000 30 6
GS-NX S 1000 6500 30 5
GS-NX S 1000 6000 30 3
GS-NX S 1000 3480 30 3
GS-NX S 1000 8000 30 2
GS-NX S 1000 4600 30 2
GS-NX S 600 8000 30 2
GS-NX S 600 6500 30 2
GS-NX S 600 6000 30 2
GS-NX S 600 5800 30 2
GS-NX S 600 2520 30 2
